Package: SpaTopic 1.2.0

Xiyu Peng

SpaTopic: Topic Inference to Identify Tissue Architecture in Multiplexed Images

A novel spatial topic model to integrate both cell type and spatial information to identify the complex spatial tissue architecture on multiplexed tissue images without human intervention. The Package implements a collapsed Gibbs sampling algorithm for inference. 'SpaTopic' is scalable to large-scale image datasets without extracting neighborhood information for every single cell. For more details on the methodology, see <https://xiyupeng.github.io/SpaTopic/>.

Authors:Xiyu Peng [aut, cre]

SpaTopic_1.2.0.tar.gz
SpaTopic_1.2.0.tar.gz(r-4.5-noble)SpaTopic_1.2.0.tar.gz(r-4.4-noble)
SpaTopic_1.2.0.tgz(r-4.4-emscripten)SpaTopic_1.2.0.tgz(r-4.3-emscripten)
SpaTopic.pdf |SpaTopic.html✨
SpaTopic/json (API)
NEWS

# Install 'SpaTopic' in R:
install.packages('SpaTopic', repos = 'https://cloud.r-project.org')

Bug tracker:https://github.com/xiyupeng/spatopic/issues

Uses libs:
  • openblas– Optimized BLAS
  • c++– GNU Standard C++ Library v3
  • openmp– GCC OpenMP (GOMP) support library
Datasets:
  • lung5 - Example input data for 'SpaTopic'

On CRAN:

Conda:

openblascppopenmp

3.00 score 631 downloads 3 exports 19 dependencies

Last updated 10 days agofrom:6799f595d0. Checks:3 OK. Indexed: no.

TargetResultLatest binary
Doc / VignettesOKMar 03 2025
R-4.5-linux-x86_64OKMar 03 2025
R-4.4-linux-x86_64OKMar 03 2025

Exports:Seurat5obj_to_SpaTopicSpaTopic_inferencestratified_sampling_sf

Dependencies:classclassIntcodetoolsDBIe1071foreachiteratorsKernSmoothmagrittrMASSproxyRANNRcppRcppArmadilloRcppProgresss2sfunitswk

SpaTopic Basics

Xiyu Peng

Rendered fromIntro_SpaTopic.Rmdusingknitr::rmarkdownon Mar 03 2025.

Last update: 2025-03-03
Started: 2024-01-18

Citation

To cite package ‘SpaTopic’ in publications use:

Peng X (2025). SpaTopic: Topic Inference to Identify Tissue Architecture in Multiplexed Images. R package version 1.2.0, https://CRAN.R-project.org/package=SpaTopic.

Corresponding BibTeX entry:

  @Manual{,
    title = {SpaTopic: Topic Inference to Identify Tissue Architecture
      in Multiplexed Images},
    author = {Xiyu Peng},
    year = {2025},
    note = {R package version 1.2.0},
    url = {https://CRAN.R-project.org/package=SpaTopic},
  }

Readme and manuals

SpaTopic

An R package for fast topic inference to identify tissue architecture in multiplexed images. It implements a novel spatial topic model to identify immunologic topics across multiple multiplexed images, simply given the cell location and cell type information as input.

Here we adapt an approach originally developed for image segmentation in computer vision, incorporating spatial information into the flexible design of regions (image partitions, analogous to documents in language modeling). We further refined the approach to address unique challenges in cellular images and provide an efficient C++ implementation of the algorithm in this R package.

Compared to other KNN-based methods (such as KNN-kmeans, the default neighborhood analysis in Seurat v5 R package), SpaTopic runs much faster on large-scale image dataset.

Installation

The R package SpaTopic now is available in CRAN and can be installed with the following code.

install.packages("SpaTopic")

The development version of SpaTopic can be installed from the GitHub repository.

# install.packages("devtools")
devtools::install_github("xiyupeng/SpaTopic")

Dependency

SpaTopic requires dependency on the following R packages:

Usage

The required input of SpaTopic is a data frame containing cells within on a single image or a list of data frames for multiple images. Each data frame consists of four columns: The image ID, X, Y cell coordinates, and cell type information.

library(SpaTopic)
packageVersion("SpaTopic")
#> [1] '1.2.0'
library(sf)
## The input can be a data frame or a list of data frames
data("lung5")
head(lung5)
#     image        X        Y           type
#1_1 image1 4215.889 158847.7      Dendritic
#2_1 image1 6092.889 158834.7     Macrophage
#3_1 image1 7214.889 158843.7 Neuroendocrine
#4_1 image1 7418.889 158813.7     Macrophage
#5_1 image1 7446.889 158845.7     Macrophage
#6_1 image1 3254.889 158838.7          CD4 T
gibbs.res<-SpaTopic_inference(lung5, ntopics = 7, sigma = 50, region_radius = 400)

For detailed usage of SpaTopic, please check the tutorial.

Example Data

The example image used in the tutorial can be downloaded from here. It is stored in a Seurat v5 object.

Example Output

The algorithm generates two key statistics for further analysis:

    1. topic content, a spatially-resolved topic distribution over cell types, and
    1. topic assignment for each cell within images.

Topic Spatial Distribution over images

Topic Content

Citation

Xiyu Peng, James W. Smithy, Mohammad Yosofvand, Caroline E. Kostrzewa, MaryLena Bleile, Fiona D. Ehrich, Jasme Lee, Michael A. Postow, Margaret K. Callahan, Katherine S. Panageas, Ronglai Shen. Decoding Spatial Tissue Architecture: A Scalable Bayesian Topic Model for Multiplexed Imaging Analysis. bioRxiv. doi: https://doi.org/10.1101/2024.10.08.617293

Contact

If you have any problems, please contact:

Xiyu Peng (pansypeng124@gmail.com, pengx@stat.tamu.edu)
