Package: nevada 0.2.0

Overview

The package nevada (NEtwork-VAlued Data Analysis) is an R package for the statistical analysis of network-valued data. In this setting, a sample is made of statistical units that are networks themselves. The package provides a set of matrix representations for networks so that network-valued data can be transformed into matrix-valued data. Subsequently, a number of distances between matrices is provided as well to quantify how far two networks are from each other and several test statistics are proposed for testing equality in distribution between samples of networks using exact permutation testing procedures. The permutation scheme is carried out by the flipr package which also provides a number of test statistics based on inter-point distances that play nicely with network-valued data. The implementation is largely made in C++ and the matrix of inter- and intra-sample distances is pre-computed, which alleviates the computational burden often associated with permutation tests.

Installation

You can install the latest stable version of nevada on CRAN with:

install.packages("nevada")

Or you can install the development version from GitHub with:

# install.packages("remotes")
remotes::install_github("astamm/nevada")

Usage

Example 1

In this first example, we compare two populations of networks generated according to two different models (Watts-Strogatz and Barabasi), using the adjacency matrix representation of networks, the Frobenius distance to compare single networks and the combination of Student-like and Fisher-like statistics based on inter-point distances to summarize information and perform the permutation test.

set.seed(123)
n <- 10L
x <- nevada::nvd(
  model = "smallworld",
  n = n,
  model_params = list(dim = 1L, nei = 4L, p = 0.15)
)
y <- nevada::nvd(
  model = "pa",
  n = n,
  model_params = list(power = 1L, m = NULL, directed = FALSE)
)

By default the nvd() constructor generates networks with 25 nodes. One can wonder whether there is a difference between the distributions that generated these two samples (which there is given the models that we used). The test2_global() function provides an answer to this question:

t1_global <- nevada::test2_global(x, y, seed = 1234)
t1_global$pvalue
[1] 0.0009962984

The p-value is very small, leading to the conclusion that we should reject the null hypothesis of equal distributions.

Although this is a fake example, we could create a partition to try to localize differences along this partition:

partition <- as.integer(c(1:5, each = 5))

The test2_local() function provides an answer to this question:

t1_local <- nevada::test2_local(x, y, partition, seed = 1234)
t1_local
$intra
# A tibble: 5 × 3
  E      pvalue truncated
  <chr>   <dbl> <lgl>
1 P1    0.175   TRUE
2 P2    0.175   TRUE
3 P3    0.175   TRUE
4 P4    0.0859  TRUE
5 P5    0.00299 FALSE

$inter
# A tibble: 10 × 4
   E1    E2      pvalue truncated
   <chr> <chr>    <dbl> <lgl>
 1 P1    P2    0.175    TRUE
 2 P1    P3    0.175    TRUE
 3 P1    P4    0.0859   TRUE
 4 P1    P5    0.0240   FALSE
 5 P2    P3    0.175    TRUE
 6 P2    P4    0.00499  FALSE
 7 P2    P5    0.000996 FALSE
 8 P3    P4    0.0140   FALSE
 9 P3    P5    0.00200  FALSE
10 P4    P5    0.0420   FALSE

Example 2

In this second example, we compare two populations of networks generated according to the same model (Watts-Strogatz), using the adjacency matrix representation of networks, the Frobenius distance to compare single networks and the combination of Student-like and Fisher-like statistics based on inter-point distances to summarize information and perform the permutation test.

n <- 10L
x <- nevada::nvd("smallworld", n)
y <- nevada::nvd("smallworld", n)

One can wonder whether there is a difference between the distributions that generated these two samples (which there is given the models that we used). The test2_global() function provides an answer to this question:

t2 <- nevada::test2_global(x, y, seed = 1234)
t2$pvalue
[1] 0.9999973

The p-value is larger than 5% or even 10%, leading us to failing to reject the null hypothesis of equal distributions at these significance thresholds.
