GauPro

Overview

This package allows you to fit a Gaussian process regression model to a dataset. A Gaussian process (GP) is a commonly used model in computer simulation. It assumes that the distribution of any set of points is multivariate normal. A major benefit of GP models is that they provide uncertainty estimates along with their predictions.

Installation

You can install like any other package through CRAN.

install.packages('GauPro')

The most up-to-date version can be downloaded from my Github account.

# install.packages("devtools")
devtools::install_github("CollinErickson/GauPro")

Example in 1-Dimension

This simple shows how to fit the Gaussian process regression model to data. The function gpkm creates a Gaussian process kernel model fit to the given data.

library(GauPro)
#> Loading required package: mixopt
#> Loading required package: dplyr
#>
#> Attaching package: 'dplyr'
#> The following objects are masked from 'package:stats':
#>
#>     filter, lag
#> The following objects are masked from 'package:base':
#>
#>     intersect, setdiff, setequal, union
#> Loading required package: ggplot2
#> Loading required package: splitfngr
#> Loading required package: numDeriv
#> Loading required package: rmarkdown
#> Loading required package: tidyr

n <- 12
x <- seq(0, 1, length.out = n)
y <- sin(6*x^.8) + rnorm(n,0,1e-1)
gp <- gpkm(x, y)
#> * Argument 'kernel' is missing. It has been set to 'matern52'. See documentation for more details.

Plotting the model helps us understand how accurate the model is and how much uncertainty it has in its predictions. The green and red lines are the 95% intervals for the mean and for samples, respectively.

gp$plot1D()

Factor data: fitting the diamonds datasetdiamonds

The model fit using gpkm can also be used with data/formula input and can properly handle factor data.

In this example, the diamonds data set is fit by specifying the formula and passing a data frame with the appropriate columns.

library(ggplot2)
diamonds_subset <- diamonds[sample(1:nrow(diamonds), 60), ]
dm <- gpkm(price ~ carat + cut + color + clarity + depth,
           diamonds_subset)
#> * Argument 'kernel' is missing. It has been set to 'matern52'. See documentation for more details.

Calling summary on the model gives details about the model, including diagnostics about the model fit and the relative importance of the features.

summary(dm)
#> Formula:
#>   price ~ carat + cut + color + clarity + depth
#>
#> Residuals:
#>     Min.  1st Qu.   Median     Mean  3rd Qu.     Max.
#> -6589.09  -217.68    37.85  -165.28   181.42  1619.37
#>
#> Feature importance:
#>   carat     cut   color clarity   depth
#>  1.5497  0.2130  0.3275  0.3358  0.0003
#>
#> AIC: 1008.96
#>
#> Pseudo leave-one-out R-squared       :   0.901367
#> Pseudo leave-one-out R-squared (adj.):   0.8427204
#>
#> Leave-one-out coverage on 60 samples (small p-value implies bad fit):
#>  68%:     0.7        p-value:   0.7839
#>  95%:    0.95        p-value:   1

We can also plot the model to get a visual idea of how each input affects the output.

plot(dm)

Constructing a kernel

In this case, the kernel was chosen automatically by looking at which dimensions were continuous and which were discrete, and then using a Matern 5/2 on the continuous dimensions (1,5), and separate ordered factor kernels on the other dimensions since those columns in the data frame are all ordinal factors. We can construct our own kernel using products and sums of any kernels, making sure that the continuous kernels ignore the factor dimensions.

Suppose we want to construct a kernel for this example that uses the power exponential kernel for the two continuous dimensions, ordered kernels on cut and color, and a Gower kernel on clarity. First we construct the power exponential kernel that ignores the 3 factor dimensions. Then we construct

cts_kernel <- k_IgnoreIndsKernel(k=k_PowerExp(D=2), ignoreinds = c(2,3,4))
factor_kernel2 <- k_OrderedFactorKernel(D=5, xindex=2, nlevels=nlevels(diamonds_subset[[2]]))
factor_kernel3 <- k_OrderedFactorKernel(D=5, xindex=3, nlevels=nlevels(diamonds_subset[[3]]))
factor_kernel4 <- k_GowerFactorKernel(D=5, xindex=4, nlevels=nlevels(diamonds_subset[[4]]))

# Multiply them
diamond_kernel <- cts_kernel * factor_kernel2 * factor_kernel3 * factor_kernel4

Now we can pass this kernel into gpkm and it will use it.

dm <- gpkm(price ~ carat + cut + color + clarity + depth,
           diamonds_subset, kernel=diamond_kernel)
dm$plotkernel()

Using kernels

A key modeling decision for Gaussian process models is the choice of kernel. The kernel determines the covariance and the behavior of the model. The default kernel is the Matern 5/2 kernel (Matern52), and is a good choice for most cases. The Gaussian, or squared exponential, kernel (Gaussian) is a common choice but often leads to a bad fit since it assumes the process the data comes from is infinitely differentiable. Other common choices that are available include the Exponential, Matern 3/2 (Matern32), Power Exponential (PowerExp), Cubic, Rational Quadratic (RatQuad), and Triangle (Triangle).

These kernels only work on numeric data. For factor data, the kernel will default to a Latent Factor Kernel (LatentFactorKernel) for character and unordered factors, or an Ordered Factor Kernel (OrderedFactorKernel) for ordered factors. As long as the input is given in as a data frame and the columns have the proper types, then the default kernel will properly handle it by applying the numeric kernel to the numeric inputs and the factor kernel to the factor and character inputs.

Kernels are stored as R6 objects. They can all be created using the R6 object generator (e.g., Matern52$new()), or using the k_<kernel name> shortcut function (e.g., k_Matern52()). The latter is easier to use (and recommended) since R will show the function arguments and autocomplete.

The following table shows details on all the kernels available.

Factor kernels: note that these all only work on a single dimension. If there are multiple factor dimensions in your input, then they each will be given a different factor kernel.

Combining kernels

Kernels can be combined by multiplying or adding them directly.

The following example uses the product of a periodic and a Matern 5/2 kernel to fit periodic data.

x <- 1:20
y <- sin(x) + .1*x^1.3
combo_kernel <- k_Periodic(D=1) * k_Matern52(D=1)
gp <- gpkm(x, y, kernel=combo_kernel, nug.min=1e-6)
#> * nug is at minimum value after optimizing. Check the fit to see it this caused a bad fit. Consider changing nug.min. This is probably fine for noiseless data.
gp$plot()

For an example of a more complex kernel being constructed, see the diamonds section above.

Intro to GPs

(This section used to be the main vignette on CRAN for this package.)

This R package provides R code for fitting Gaussian process models to data. The code is created using the R6 class structure, which is why $ is used to access object methods.

A Gaussian process fits a model to a dataset, which gives a function that gives a prediction for the mean at any point along with a variance of this prediction.

Suppose we have the data below

x <- seq(0,1,l=10)
y <- abs(sin(2*pi*x))^.8
ggplot(aes(x,y), data=cbind(x,y)) +
  geom_point()

A linear model (LM) will fit a straight line through the data and clearly does not describe the underlying function producing the data.

ggplot(aes(x,y), data=cbind(x,y)) +
    geom_point() +
    stat_smooth(method='lm')
#> `geom_smooth()` using formula = 'y ~ x'

A Gaussian process is a type of model that assumes that the distribution of points follows a multivariate distribution.

In GauPro, we can fit a GP model with Gaussian correlation function using the function gpkm.

library(GauPro)
gp <- gpkm(x, y, kernel=k_Gaussian(D=1), parallel=FALSE)

Now we can plot the predictions given by the model. Shown below, this model looks much better than a linear model.

gp$plot1D()

A very useful property of GP’s is that they give a predicted error. The red lines give an approximate 95% confidence interval for the value at each point (measure value, not the mean). The width of the prediction interval is largest between points and goes to zero near data points, which is what we would hope for.

GP models give distributions for the predictions. Realizations from these distributions give an idea of what the true function may look like. Calling $cool1Dplot() on the 1-D gp object shows 20 realizations. The realizations are most different away from the design points.

if (requireNamespace("MASS", quietly = TRUE)) {
  gp$cool1Dplot()
}

Using kernels

The kernel, or covariance function, has a large effect on the Gaussian process being estimated. Many different kernels are available in the gpkm() function which creates the GP object.

The example below shows what the Matern 5/2 kernel gives.

kern <- k_Matern52(D=1)
gpk <- gpkm(matrix(x, ncol=1), y, kernel=kern, parallel=FALSE)
if (requireNamespace("MASS", quietly = TRUE)) {
  plot(gpk)
}

The exponential kernel is shown below. You can see that it has a huge effect on the model fit. The exponential kernel assumes the correlation between points dies off very quickly, so there is much more uncertainty and variation in the predictions and sample paths.

kern.exp <- k_Exponential(D=1)
gpk.exp <- gpkm(matrix(x, ncol=1), y, kernel=kern.exp, parallel=FALSE)
if (requireNamespace("MASS", quietly = TRUE)) {
  plot(gpk.exp)
}

Trends

Along with the kernel the trend can also be set. The trend determines what the mean of a point is without any information from the other points. I call it a trend instead of mean because I refer to the posterior mean as the mean, whereas the trend is the mean of the normal distribution. Currently the three options are to have a mean 0, a constant mean (default and recommended), or a linear model.

With the exponential kernel above we see some regression to the mean. Between points the prediction reverts towards the mean of 0.2986876. Also far away from any data the prediction will near this value.

Below when we use a mean of 0 we do not see this same reversion.

kern.exp <- k_Exponential(D=1)
trend.0 <- trend_0$new()
gpk.exp <- gpkm(matrix(x, ncol=1), y, kernel=kern.exp, trend=trend.0, parallel=FALSE)
if (requireNamespace("MASS", quietly = TRUE)) {
  plot(gpk.exp)
}
